☆Cisco Viptela 1000 [vEdge-1000-AC]！(#J3-507)「80サイズ」☆

U-Boot 2012.04.01-g159ebf0 (Build time: Nov 11 2015 - 09:10:47)

Skipping PCIe port 0 BIST, in EP mode, can't tell if clocked.
Skipping PCIe port 1 BIST, reset not done. (port not configured)
BIST check passed.
CUST_N821 board revision major:3, minor:1, serial #: 11OD214315****
OCTEON CN6130-AAP pass 1.1, Core clock: 1000 MHz,
IO clock: 600 MHz, DDR clock: 533 MHz (1066 Mhz DDR)
Base DRAM address used by u-boot: 0x10f800000, size: 0x800000
DRAM: 4 GiB
Clearing DRAM...... done
CPLD device 007c rev 09 (board rev 01)
Flash: 16 MiB
PCIe: Port 0 is SGMII, skipping.
PCIe: Port 1 link active, 1 lanes, speed gen2
PCI console init succeeded, 1 consoles, 1024 bytes each
Net:   octmgmt0, octeth0, octeth1, octeth2, octeth3,
octeth4, octeth5, octeth6, octeth7
MMC:   not available
USB:   USB EHCI 1.00
scanning bus for devices... 2 USB Device(s) found
Type the command 'usb start' to scan for USB storage devices.

reset timer off, running from bank 1
Hit ctrl-x to stop booting 0
writing 0x303 to addr: 0x8001180000001628
(Re)start USB...
USB:   USB EHCI 1.00
scanning bus for devices... 2 USB Device(s) found
       scanning bus for storage devices... 1 Storage Device(s) found
Allocated 0x20000000 bytes at address: 0x30000000, name: almushtarika
Loading file "/boot/viptela-fp.bin" from usb device 0:1 (usbda1)
20308623 bytes read
Bootloader: Done loading app on coremask: 0xe
Loading file "/boot/vmlinux" from usb device 0:1 (usbda1)
10481853 bytes read
argv[2]: coremask=1
argv[3]: endbootargs
Allocating memory for ELF segment: addr: 0xffffffff84000000
(adjusted to: 0x4000000), size 0x905a40
## Loading big-endian Linux kernel with entry point: 0xffffffff84532da0 ...
Bootloader: Done loading app on coremask: 0x1
Starting cores 0xf
sP1:~CONInSiOtLiEa->l iUzsiinngg  cgdreovuipc es utbrseye
  cpuset
Initializing cgroup subsys cpu
Linux version 3.4.27-rt37-cavium (jenkins@jenkins.eng.viptela.com)
(gcc version 4.7.2 (GCC) ) #1 SMP PREEMPT Wed Sep 23 15:42:01 PDT 2015
CVMSEG size: 2 cache lines (256 bytes)
Cavium Inc. SDK-3.0
bootconsole [early0] enabled
CPU revision is: 000d9301 (Cavium Octeon II)
Checking for the multiply/shift bug... no.
Checking for the daddiu bug... no.
Determined physical RAM map:
memory: 000000000a400000 @ 0000000004a00000 (usable)
memory: 0000000010000000 @ 0000000020000000 (usable)
memory: 000000009dc00000 @ 0000000052400000 (usable)
memory: 000000000ffff000 @ 00000000f0001000 (usable)
memory: 000000000f7ff000 @ 0000000100001000 (usable)
memory: 0000000000058000 @ 00000000047c8000 (usable after init)
sd 0:0:0:0: [sda] No Caching mode page present
sd 0:0:0:0: [sda] Assuming drive cache: write through
sd 0:0:0:0: [sda] No Caching mode page present
sd 0:0:0:0: [sda] Assuming drive cache: write through
sd 0:0:0:0: [sda] No Caching mode page present
sd 0:0:0:0: [sda] Assuming drive cache: write through
INIT: version 2.88 booting
Starting udev
Starting Bootlog daemon: bootlogd.
Configuring network interfaces... done.
Fri Dec 18 19:11:00 UTC 2015
INIT: Entering runlevel: 5
Starting vedge: sysmgr.
Stopping Bootlog daemon: bootlogd.

Viptela 15.3.6
vedge login: admin
Password:
Last login: Fri Dec 18 19:09:12 UTC 2015 on ttyS0
Welcome to Viptela CLI
admin connected from 127.0.0.1 using console on vedge
vedge# show hardware inventory
hardware inventory Chassis 0
version        3.1
part-number    vEdge-1000
serial-number  11OD214315****
hw-description "vEdge-1000. CPLD rev: 0x9, sig: 0x7c"
hardware inventory CPU 0
version        None
part-number    None
serial-number  None
hw-description "Quad-Core Octeon-II"
hardware inventory DRAM 0
version        None
part-number    None
serial-number  None
hw-description "4096 MB DDR3"
hardware inventory Flash 0
version        None
part-number    None
serial-number  None
hw-description "Flash: Type - nor, Size - 16.00 MB"
hardware inventory eMMC 0
version        None
part-number    None
serial-number  None
hw-description "eMMC: Size - 7.31 GB"
hardware inventory PIM 0
version        None
part-number    ge-fixed-8
serial-number  None
hw-description "8x 1GE Fixed Module"
hardware inventory FanTray 0
version        None
part-number    None
serial-number  None
hw-description "Fixed Fan Tray - 2 Fans"
vedge# show version
15.3.6
vedge# show running-config system
system
vbond ztp.viptela.com
aaa
  auth-order local radius tacacs
  usergroup basic
   task system read write
   task interface read write
  !
  usergroup netadmin
  !
  usergroup operator
   task system read
   task interface read
   task policy read
   task routing read
   task security read
  !
  user admin
   password $6$pHGkwEr3EhAwtD3a$DQGCsyZ81THsF7RJPX
qtrT4tK1dyvEC3pXeVOX9zzOmAObIch2zyWQW1.
CnNlhokX5XxGcGW5Embk7/nqP61j/
  !
!
logging
  disk
   enable
  !
!
!
vedge#
vedge# show system status

Viptela (tm) vedge Operating System Software
Copyright (c) 2013-2015 by Viptela, Inc.
Version: 15.3.6

System logging to host  is disabled
System logging to disk is enabled

Last reboot:             Initiated by user admin via cli - reboot command.
System uptime:           0 days 00 hrs 12 min 33 sec
Current time:            Fri Dec 18 19:23:28 UTC 2015

Load average:            1 minute: 0.11   5 minutes: 0.15   15 minutes: 0.17
Processes:               128 total, 2 running
CPU states:              10.30% user,   4.00% system,   85.10% idle
Memory usage:            3408436K total,    596288K used,   2725112K free
                         5980K buffers,  81056K cache

Disk usage:              Filesystem      Size  Used  Avail  Use%  Mounted on
                         /dev/root       3.6G  320M  3.2G   10%   /

Personality:             vedge
Services:                None
vManaged:                false
Commit pending:          false
Configuration template:  None

vedge# show license list
LIST OF PACKAGES
licenses
base-files
base-passwd
bash
bridge-utils
busybox
bzip2
confd
coreutils
curl
cvmx-remote-utils
dmidecode
e2fsprogs
ethtool
file
freeradius-client
gdb
grep
i2c-tools
init-ifupdown
initscripts
iproute2
iptables
jemalloc
kmod
libconfd
libevent
libpam
libumem
linux-firmware-cs4321
logrotate
lsof
minicom
modutils-initscripts
mtd-utils
ncurses
net-tools
netbase
nmap
ntp
oct-linux-mdio
openssh
openssl
pam-radius
pam-tacplus
parted
pax
perl
ppp
procps
protobuf
protobuf-c
quagga
rp-pppoe
rpm-postinsts
shadow
shadow-securetty
socat
sqlite3
strace
stund
sysfsutils
sysklogd
sysvinit
sysvinit-inittab
tar
tcpdump
tinylogin
tunctl
tzdata
u-boot-fw-utils
u-boot-n821
u-boot-n822
udev
udev-extraconf
update-rc.d
viptela-cp
viptela-fp
xz
vedge#
